Detail Produk

SR2 Wireless Minipci 400mW BG

klik pada gambar untuk melihat gambar lebih besar

Kategori : Interface Kode : SR2 Harga : Rp 1.195.000,00   The world's first hi-performance 2.4 GHz 802.11b/g mini-PCI module. With improved output power and sensitivity over standard wireless cards, the SuperRange2 is ideal for mesh networking, telematics, and other embedded applications. Including MMCX - NFemale pigtail.   download brosur (pdf)

Spesifikasi Teknis:

• Chipset: Atheros, 4th Generation, AR5213
• Radio Operation: IEEE 802.11b/g, 2.4GHz
• Wireless Modular Approvals: FCC Part 15.247, CE(100mW limited)
• TX Channel Width Support: 5MHz / 10MHz / 20MHz / 40MHz
• RoHS Compliance: YES
• Security: WPA, WPA2, AES-CCM & TKIP Encryption, 802.1x, 64/128/152bit WEP
• Data Rates: 6Mbps, 9Mbps, 12Mbps, 24Mbps, 36Mbps, 48Mbps. 54Mbps
• Antenna Ports: u.fl (main), MMCX (secondary)
• Temperature: Range -40C to +80C
• Interface: 32-bit mini-PCI Type IIIA
• Operation Voltage: 3.3VDC
• Max Power Output: 400 mWatt


Seluruh harga yang tercantum di atas belum termasuk PPN 10% dan biaya pengiriman.
